WINDSOR HOT & BAIN MARIE
COUNTER TOP
HOT
- Curved Glass Profile
- Front - Fixed Glass
- Rear - Sliding Doors
- Single Glazed
- Side & Top Lighting
- Standard Colour - Black Ripple
- Stainless Steel Top
- Stainless Steel Internal Floor
- Chrome Wire Shelves (Adjustable Height and Tilt)
- 4 Display Shelves
- Thermostatically Controlled 30ºC - 95ºC
- Insulated (CFC free) Top for Safety and Improved Performance
- Built In Water Dish
- Doors Lift Out for Easy Cleaning
- Adjustable Feet
|
BAIN MARIE
- Curved Glass Profile
- Front - Fixed Glass
- Single Glazed
- Rear - Open
- Halogen Lamps
- Stainless Steel Well
- Standard Colour - Black Ripple
- Stainless Steel Top
- Chrome Wire Shelf Above Lights
- Operates Wet or Dry
- Drain in Bottom of Well
- Gastronorm Dishes not Included
- Thermostatically Controlled 30ºC - 95ºC
- Main Divide Bars Included
- Adjustable Feet
|
|
|
HOT
|
BAIN MARIE
|
| Model Number | WH6 | WH9 | WH12 | WB7 | WB11 | WB14 | WB17 |
| Overall Length |
600 |
900 |
1200 |
745 |
1070 |
1395 |
1720 |
| Overall Depth |
665 |
665 |
665 |
665 |
665 |
665 |
665 |
| Overall Height |
795 |
795 |
795 |
795 |
795 |
795 |
795 |
| Side / Top Lights |
2 |
2/1 |
2/1 |
 |
|
|
|
| Shelves |
4 |
4 |
4 |
1 |
1 |
1 |
1 |
| No. of 1/2 Pans 100mm Deep (Not supplied) |
|
|
|
2x2 |
3x2 |
4x2 |
5x2 |
| Options | Code | | | | | | | |
| Front - Sliding Doors |
FSD |
 |
|
|
|
|
|
|
| Colour Coordinate Strip (Orica Powdercoat Colours) |
CCS |
|
|
|
|
|
|
|
| Specifications | | | | | | | |
| Power Rating / 3 Pin Plug (Amps) |
6.7/10 |
8.9/10 |
13.3/15 |
9.0/15 |
11.1/15 |
15.0/15 |
20.0/No |
| Display Area (m2) |
1.0 |
1.4 |
2.1 |
|
|
|
|
| Cabinet Weight (Kg) |
53 |
80 |
106 |
48 |
72 |
103 |
126 |
| Cabinet Volume (m3) |
0.24 |
0.36 |
0.49 |
0.30 |
0.43 |
0.56 |
0.70 |
|
|
Notes:
- All Cabinets are designed as Food Presentation Cabinets. Product must be at correct temperature prior to displaying in cabinet.
- Specifications subject to change without notice.
- Alternative options & custom design available on request.
- Shelves in hot cabinets can be height adjusted in 25mm increments in a flat or tilted position.
- Powder coat colour of your choice is based on the Orica range (made to order and some special effects colours not included).
- Proudly New Zealand made.
|
|
DATA SHEET
